JAE 4 Way Cable Mount MIL Spec Circular Connector Plug, Pin Contacts,Shell Size 18
- RS Stock No.:
- 5470432
- Mfr. Prt No.:
- N/MS3106B18-10P
- Brand:
- JAE
Technical Reference
Legislation and Compliance
RoHS Status: Not Applicable
Statement of Conformity
RS Components
Statement of Conformity
This statement confirms that the product detailed below complies with the specifications currently published in the RS media and has been subject to the strict quality conditions imposed by RS Components’ internal management systems. Furthermore and where applicable, it confirms that all relevant semiconductor devices have been handled and packed under conditions that meet the administrative and technical requirements of ANSI/ESD S20.20 and EN61340-5-1 electrostatics control standards.
Compliant Product Details
| RS stock number | 5470432 |
| Product description | JAE 4 Way Cable Mount MIL Spec Circular Connector Plug, Pin Contacts,Shell Size 18 |
| Manufacturer / Brand | JAE |
| Manufacturer part number | N/MS3106B18-10P |
The foregoing information relates to product sold on, or after, the date shown below.
RS COMPONENTS
| Date | Dec 26, 2024 |
RS Components Pte Ltd Robinson Road, P.O. Box 1582, Singapore 903132
Country of Origin: JP
Product Details
Specifications
| Attribute | Value |
| Brand | JAE |
| Number of Contacts | 4 |
| Gender | Male |
| Contact Gender | Male |
| Current Rating | 23 A |
| Voltage Rating | 500 V ac |
| Shell Size | 18 |
| Mounting Type | Cable Mount |
| Termination Method | Solder |
| Body Orientation | Straight |
| Colour | Black |
| Minimum Operating Temperature | -30 °C |
| Maximum Operating Temperature | +85 °C |
| Contact Plating | Silver |
| Shell Plating | Zinc |
| Contact Material | Copper Alloy |
