Phoenix Contact IFS-USB-DATACABLE Series USB Cable, for use with QUINT UPS and TRIO UPS
- RS Stock No.:
- 8016404
- Mfr. Prt No.:
- 2320500
- Brand:
- Phoenix Contact
Technical Reference
Legislation and Compliance
RoHS Certificate of Compliance
EU Directives 2011/65/EU and 2015/863 restrict the use of the 10 substances below in the manufacture of specified types of electrical equipment.
Whilst this restriction does not legally apply to components, it is recognised that component “compliance” is relevant to many customers.
RS definition of RoHS Compliance:
- The product does not contain any of the restricted substances in concentrations and applications banned by the Directive,
- and for components, the product is capable of being worked on at the higher temperatures required by lead–free soldering
The restricted substances and maximum allowed concentrations in the homogenous material are, by weight:
| Substance | Concentration |
| Lead | 0.1% |
| Mercury | 0.1% |
| PBB (Polybrominated Biphenyls) | 0.1% |
| PBDE ( Polybrominated Diphenyl Ethers) | 0.1% |
| Hexavalent Chromium | 0.1% |
| Cadmium | 0.01% |
| DEHP (Bis (2-Ethylhexl) phthalate) | 0.1% |
| BBP (Benzyl butyl phthalate) | 0.1% |
| DBP (Dibutyl phthalate) | 0.1% |
| DIBP (Diisobutyl phthalate) | 0.1% |
The supplier of the item listed below has informed RS Components that the product is "RoHS Compliant".
RS Components has taken all reasonable steps to confirm this statement. Information relates only to products sold on or after the date of this certificate.
| RS stock number | 8016404 |
| Product description | Phoenix Contact IFS-USB-DATACABLE Series USB Cable, for use with QUINT UPS and TRIO UPS |
| Manufacturer / Brand | Phoenix Contact |
| Manufacturer part number | 2320500 |
RS Components Ltd, Birchington Road, Corby, Northants, NN17 9RS, UK
Statement of Conformity
This statement confirms that the product detailed below complies with the specifications currently published in the RS media and has been subject to the strict quality conditions imposed by RS Components’ internal management systems. Furthermore and where applicable, it confirms that all relevant semiconductor devices have been handled and packed under conditions that meet the administrative and technical requirements of ANSI/ESD S20.20 and EN61340-5-1 electrostatics control standards.
| RS stock number | 8016404 |
| Product description | Phoenix Contact IFS-USB-DATACABLE Series USB Cable, for use with QUINT UPS and TRIO UPS |
| Manufacturer / Brand | Phoenix Contact |
| Manufacturer part number | 2320500 |
The foregoing information relates to product sold on, or after, the date shown below.
RS COMPONENTS
| Date | Nov 17, 2024 |
RS Components Pte Ltd Robinson Road, P.O. Box 1582, Singapore 903132
Country of Origin: DE
Product Details
Phoenix Contact IFS-USB Communication Cable
From Phoenix Contact, the IFS-USB data cable used for the communication between industrial PC’s and Phoenix Contact devices featuring the 12 position IFS data port. Compatible devices include QUINT UPS’s and TRIO UPS’s.
The 3m black cable has a 12 position IFS angled male connector (PC side) to a straight USB type A male connector (Device side)
Features and Benefits
- Robust and reliable
- Constructed from high-quality materials
- Fully moulded with strain relief
- USB 2.0 Full speed
- -25˚ C to + 70 ˚ C operating temperature range
- Conforms with EMC Directive 2014/30/EU
- EN 61000-6-4 and EN 61000 -6-2 compliant
Applications
The Phoenix Contact 2320500 IFS-USB cable is designed for the transmission of data from Industrial PC’s to UPS’s (Uninterruptible Power Supplies). The cable ensures the data is reliably sent from the PC to the UPS. Some of the common areas are
- Industrial networks
- Assembly lines
- Monitoring and configuration
Specifications
| Attribute | Value |
| Brand | Phoenix Contact |
| For Use With | QUINT UPS and TRIO UPS |
| Series | IFS-USB-DATACABLE |
